American Bright not only offers manifold infrared discrete LEDs, but is capable of designing and manufacturing customized IR modules such as motor assemblies and encoder sensors.
Photo Interrupter:
is usually composed of a light emitter and a light receiver, which are aligned facing each other in one package. It acts as an optical switch by defecting the blockage of the light emitted by the emitter.
Photocoupler:
is also called optoisolator, which contains an infrared emitting diode and a silicon phototransistor. It usually acts as optical links and provides electrical isolation between two separate circuits.
Receiving Module:
includes photo-diode that receives the radiation emitted by the IR emitter, pre-amplifier/amplifier that amplifies signal, and band pass filter that filters out ambient noise. All in one device provides excellent performance in disturbed ambient light environment.
Applications: garage door opener, TV/VCR, audio system, toilet sensor,
Photo Transistor:
is a type of transistor which receives light photon and converts the light energy into an electrical current and voltage.
Photo Diode:
is a type of semi-conductor diode which receives light photon and converts the light energy into an electrical current.
Infrared Emitter:
is light emitting diode which emits light with wavelength over 700nm. Infrared is not visible by human eyes. Through hole and surface mount are available. Available wavelength in 850nm and 940nm.
More Applications of Infrared Products…
Upcoming New Products
- Packages in 3535 Ceramics/ 3838 EMC
- Emitting wavelength: 810nm/ 850nm/ 940nm
- Radiant Flux: 240-550mW @ 350mA
- Viewing angles: 60˚/90˚/120˚
- High operating temperature(-55˚C to 110˚C)
- Packages available in DIP4, SOP4, SOP5, LSOP4, DIP6, DIP7, DIP, etc
- Wide categories: Transistor, Darlington Transistor, TRIAC, High Speed, Schmitt Trigger, IGBT Gate Driver, Photo Relay
